Dimension(ID/OD): 8.5MM / 14MM
Working pressure: 0 – 5 bar
Working temperature: ≤ 70℃
Tensile strength: ≥ 500N
Flow rate: ≥ 25.2L/Min at 3 bar
Thermal shock test: 300 cycles with flow rate of 6L/Min (EN1113)
Life cycle test: 10,000 cycles under the force of 67N (ASME A112.18.1/

CSA B125.1)
5,000 cycles under the force of 5N ( EN1113)
Approvals: EN1113, WRAS
This hose can be customized to meet UPC, CSA,KTW-C,W270,WATERMARK,ACS and other international certifications.
