Out jacket: Stainless steel or brass;
                  Double-lock;
Dimension(ID/OD): 7MM / 12.5MM; 7MM / 14MM
Inner hose: EPDM(WRAS, WATERMARK, ACS),
                  TPE(NSF, UPC, CSA, WRAS)
                  Silicone(KTW,W270)
Working pressure: 0 – 5 bar
Working temperature: ≤ 70℃
Tensile strength: ≥ 500N
Flow rate: ≥ 25.2L/Min at 3 bar
Thermal shock test: 300 cycles with flow rate of 6L/Min (EN1113)
Life cycle test: 10,000 cycles under the force of 67N (ASME A112.18.1 /

                       CSA B125.1)
                       5,000 cycles under the force of 5N ( EN1113)

This hose can be customized to meet WRAS, NSF, UPC, CSA, KTW-C, W270, WATERMARK and other international certifications.
